This range of compactors are sealed units, making them suitable for a wide range of waste products whether wet or dry and are particularly useful in situations where hygiene or environmental situations require a sealed unit.
They are designed to allow the control panel to be mounted to either side to suit the requirements of the customer.
Users will receive email and/or text message notifications when the machine is 75% full and again when it requires emptying.
We are able to vary settings and check for faults electronically directly from our office in order to optimise the performance of your machine to the waste product being processed. This also reduces the time our engineers need to spend on site should any issues need to be addressed and of course leads to savings for the customer.
Loading doors located to both sides together with a large front/top loading door suitable for tipping skips.
They are designed and built to be bin lift compatible and to the British Chem standard.
Power supply: | 16 amp, 3 ph, 415 V, Min. D type motor rated breaker- | ||
machine is fitted with 5 pin 16 amp plug | |||
Motor size: | 5.5 kW | ||
Cycle time: | 30 sec | ||
Hydraulic pressure: | 230 bar max, 200 bar working | ||
Head force: | 30 ton max, 25 ton working | ||
Compaction head: | width = 1805 mm, height = 575 mm, stroke = 1275 mm | ||
Capacity: | 18.3 m3 (23 yd3) | 20 m3 (27 yd3) | 25 m3 (32 yd3) |
Side loading door: | load height from ground 1062 mm | ||
Side door opening: | 800 mm wide x 1080 mm high | ||
Front loading door: | load height from ground 1890 mm | ||
Front door opening: | 1780 mm x 1605 mm | ||
Machine height: | 2250 mm | 2764 mm | 2764 mm |
Machine width: | 2250 mm | 2468 mm | 2468 mm |
Machine length: | 5936 mm | 6156 mm | 6643 mm |
Machine weight: | 4.7 tonne | 5.2 tonne | 5.5 tonne |
GPRS system: | integrated modem and sim card. | ||
fill level monitor and report via email. | |||
machine performance monitor and report via email. |
The CBS 18 (S) has been specifically designed to fit inside a shipping container.
